Safety: Class II anti-falling object protection cab, safe control design
Fast: Quick and lightweight attachment quick-change system at the front
Sturdy: high-strength frame and boom lift
Full range: from JC25-JC120, load from 300kg-1400kg, from radial lift to vertical lift, from wheeled to crawler, a full range of skid steer loaders
Strong and durable power, high work efficiency, low fuel consumption, low noise, good reliability and long service life.
INFRONT mini skid steer supports customization.
Main Technical Specifications
|
Item |
YF25 |
|
Operating load (kg) |
300 |
|
Max Speed(km/h) |
9 |
|
Rated flux (L/min) |
37 |
|
Tire(track) model |
23×8.5-15 |
|
Rated power (Kw) |
22.2 |
|
Fuel tank capacity (L) |
25 |
|
self weight bucket (kg) |
1500 |
|
Bucket capacity (m³) |
0.2 |
|
Overall operating height (mm) |
3126 |
|
Height to bucket hinge pin (mm) |
2399 |
|
height to top of cab (mm) |
1813 |
|
Height to bottom of level bucket(mm) |
2399 |
|
Without bucket length(mm) |
1918 |
|
overall length with bucket(mm) |
2560 |
|
Dumping angle at maximum height(°) |
36 |
|
Dumping height(mm) |
1882 |
|
Dumping reach(mm) |
458 |
|
Rollback o bucket on ground(°) |
24 |
|
Rollback of bucket at full height(°) |
97 |
|
Wheelbase(mm) |
722 |
|
Ground clearance(mm) |
148 |
|
Angle of departure(°) |
28 |
|
Front turning radius without bucket(mm) |
971 |
|
Front tuning radius(mm) |
1557 |
|
Rear tuning radius(mm) |
1146 |
|
Rear axle to bumper (mm) |
738 |
|
Tread width (mm) |
747 |
|
Width (mm) |
900 |
|
Bucket width (mm) |
914 |
