High fuel efficiency, super power
Lower fuel Consumption, high configuration, superior performance
Saving energy and protecting environment.
Bucket, oil cylinder production plate and bottom plate are made of high strength cast steel.
The accessibility and stability of the narrow space coexist, and the strong structure will not produce a sense of shaking when the track bandwidth is extended. No need to consider the width of the construction site can still maintain high efficiency.
This excavator is designed for small project, garden, farmland municipal works etc, also can be used in playground, public park. It is with small engine, simple design, easy to maintain, it's reliable and of user-friendly. With multiple functions of digging, grabbing, drilling, bull-dozing, ditch-cleaning and rock-breaking.
|
Performance Parameter |
Units |
W20-5 |
|
|
Machine weight |
kg |
1920 |
|
|
Bucket |
Capacity |
m³ |
0.046 |
|
Width |
mm |
400 (excludes side edges) |
|
|
Max Excavating force |
KN |
15.2 |
|
|
Engine |
Model name |
kubota |
|
|
Displacement |
L (cc) |
1.028 |
|
|
Output power |
Kw (PS) |
12.5 |
|
|
Performance |
Swing speed |
r/min |
7.5 |
|
Running speed (low/ high) |
km/h |
2/3.5 |
|
|
Ground pressure |
Kpa (kgf/c㎡) |
25(0.24) |
|
|
Gradeability |
%(degree) |
58(30) |
|
|
Dozer blade (W*H) |
mm |
1240*268 |
|
|
Swing angle |
degree (°) |
65/58 |
|
|
Scope of work |
||
|
Max. digging height |
mm |
3540 |
|
Max. unloading height |
mm |
2440 |
|
Max. digging depth |
mm |
2310 |
|
Max. vertical mining depth |
mm |
1910 |
|
Max. digging radius |
mm |
3900 |
|
Min. turning radius |
mm |
1430 |
|
Max. bulldozing height |
mm |
245 |
|
Max. depth of bulldozing |
mm |
200 |
