High Efficiency and Low Consumption Engine
The working mode can be changed on the monitor, which can maximize the operating efficiency and reduce the fuel consumption.
Large-capacity Fuel Tank with Anti-rust Treatment
The large capacity of fuel tank reduces the frequency of refueling. The interior of the fuel tank has been well treated against rusting. No rusting will occur even if the tank is soaked in oil containing water and phosphoric acid and other chemicals for a long period of time.
Standard crushing pipeline, can be equipped with a variety of crushing hammer, pine, grab, nephew drill and other different accessories, one machine multi-purpose; Iron track and rubber track can be exchanged at any time, adapt to various working conditions of construction, the use of partial rotation arm, can be deflected to work easily dug wall foot.
Specification
|
Operating weight |
4000kg |
|
Digging bucket capacity |
0.26cbm |
|
Diesel tank capacity |
60L |
|
Hydraulic oil tank capacity |
75L |
|
Engine |
Laidong 490 or Yanmar |
|
Rated power |
37kw/2200r/min |
|
Machine length |
4500mm |
|
Upper frame/ Chassis width |
1520mm |
|
Machine height |
2650mm |
|
Platform ground clearance |
557mm |
|
Max. Digging depth |
2250mm |
|
Max. Digging height |
3900mm |
|
Max. Dumping height |
3100mm |
|
Max. Digging radius on ground |
1250mm |
|
Min. Radius of gyration |
1820mm |
|
Max. Lifting height of dozer |
359mm |
|
Max. Digging depth of dozer |
268mm |
|
Min. Tail swing radius |
1170mm |
|
Rated working pressure |
22mpa |
|
Walking motor |
2 speed plunger type |
|
Swing motor |
Variable plunger type |
|
Main pump |
32cc plunger type |
|
Flow |
99 |
|
Climbing ability |
35° |
|
Max. Digging force bucket/arm |
55.6kn (5560iso) |
|
Travel speed low/high |
2.7/4.6km/h |
|
Swing speed |
9-11r/min |
|
Steel tracks pressure on ground |
34.8kpa (0.355kgf/cm2) |
