Excellent factory: 16 years of experience, German engineers help optimize the product.
European style: the exterior design conforms to the European market aesthetics.
Compact size: perfect for indoor confined spaces, farm works, road works , and moving material on construction and excavation sites.
EU Stage V engine, CE certification: strictly comply with European market regulations and requirements.
Exclusive hydraulic quick-coupler: solved the problem of easy fracture.
Customized acceptable: Logo, color, buckets, tires, and attachments.
|
Performance |
Rated loading |
2600kg |
|
Overall weight |
5500kg |
|
|
Rated bucket capacity |
1.3m³ |
|
|
Maximum tractive force |
≥54KN |
|
|
Maximum breakout force |
≥45.4KN |
|
|
Maximum grade ability |
30° |
|
|
Maximum dump height |
3300mm |
|
|
Optional maximum dump height |
3500mm |
|
|
Overall dimension (L×W×H) |
5890×2000×2850mm |
|
|
Minimum turning radius |
5330mm |
|
|
Engine |
Model |
YUNNEI turbocharged engine |
|
Optional model |
YTO/YUCHAI/CUMMINS/YANMAR/KOHLER engine |
|
|
Type |
Vertical, in-line, water cooled, 4-stroke diesel engine |
|
|
Rated power |
65KW |
|
|
Rated speed |
2200rpm-2400rpm |
|
|
Engine starting mode |
Electric |
|
|
Transmission system |
Gearbox mode |
Counter shaft power-shift |
|
Gear shift |
2 forward shift 2 reverse shift |
|
|
Maximum speed |
25km/h |
|
|
Drive axles |
Main reducing spiral |
Circular Arc Bevel gear, single stage |
|
Decelerating mode |
Single stage planetary type |
|
|
Wheel base (mm) |
2400mm |
|
|
Wheel tread |
1640mm |
|
|
Ground clearance |
310mm |
|
|
Driving mode |
Four-wheel full hydraulic drive |
|
|
Tire |
Tire type |
16/70-20 |
|
Optional tire |
16/70-24 |
|
|
Brake |
Brake mode |
Air assist disc brake on 4 wheels |
|
Packaging |
Packaging details |
1 unit packed into 20GP,2 units packed into 40HQ. |
|
Port |
Qingdao |
|
|
Warranty |
12 months after delivery or 1500 work hours(whichever comes first) |
|
|
Delivery time |
15-25 days after 30% down payment |
|
Why choose us?
- Our team of engineers, designers, and technicians work together to produce Wheel Loaders that exceed our customer's expectations.
- Our company will continue to create high quality Loader Min by adhering to the spirit of being sincere, better and newer, giving full play to our professional advantages.
- Our Wheel Loaders are cost-effective solutions designed to help our customers increase productivity and profitability.
- We have achieved our commitment in terms of product quality, delivery date, technical service, training, compensation for breach of contract and service hotline so that users can rest assured of our products.
- We stand behind our products and offer a comprehensive warranty to ensure our customers' peace of mind.
- Our company's products are famous for their quality. We strictly control every link of product production. Our slogan is that it is better not to produce than to meet the standards.
- We are constantly investing in our facility and technology to ensure that we are always at the forefront of manufacturing innovation.
- We realize the effective combination of low cost and high quality to achieve maximum efficiency.
- Our Wheel Loaders are designed to be highly reliable, reducing downtime and increasing productivity for our customers.
- We build an ambitious, responsible and respected team, and construct an international operation with industry competitiveness.
