compact skidsteer

Product advantages

The YF480 compact skidsteer is flexible, easy to operate, and has passed EPA/Euro 5/CE certification.
The YF480 compact skidsteer uses imported Briggs & Stratton engines or Honda engines.
The YF480 compact skidsteer is reasonably priced, with a full range of buckets and standard automatic bucket leveling. The YF480 compact skidsteer adopts a hidden boom cylinder design and is widely used in agriculture, construction and other fields.

Model	YF480	YF480
Lifting Capacity(KG)	450	450
Engine Type	HONDA HGX690	Briggs & Stratton 3864
Engine Capacity(kw/Hp)	25hp	23hp
Displacement cm3/Number of cylinders	688/2	698/2
Rotation speed per minute(rpm)	3600	3600
Maximum torque NM/rpm	38.6/2500	50/3000
Cooling method	Air-cooled	Air-cooled
Fuel/Fuel tank capacity	Gasoline 95#/20L	Gasoline 95#/20L
Drive System	Hydraulic four-wheel drive	Hydraulic four-wheel drive
Speed(km/h)	0-5.5(By Scale)	0-5.5(By Scale)
Enhancement of capabilities(kg)	350	300
Traction force(kg)	409	400
Hydraulic drive system(L/bar)	35/200	50/180
Hydraulic oil tank capacity(L)	40	35
Standard Tires	22*11.00-8	18*8.5-8
Electrical system(V)	12	12
Battery Capacity(Ah)	45	36
Braking System	Hydraulic enclosed brake	Hydraulic enclosed brake
Drive	Skid steering	Skid steering
Hydraulic Cylinder Thrust(KG)	600	600
Overall Dimensions(MM)	152510501258	148511501300
Machine Weight(KG)	900	900
