1. Engine: Kubota engine optional, 3-cylinder air cooled, 14KW.
2. Hydraulic pump (gear pump) is easy to maintain, long life
3. Strong lift and dig performance helps you get the job done faster. The retractable undercarriage lets you access and work in the tightest areas. Dig-to-blade and dozer float features allow for easy clean up.
4. Multiple valves under the operating handle,The benefit of less effort and improved control is in your hands!
5. Rubber track no damage to cement, tile floor.
Specificaton
|
Operating Weight |
2500kg |
|
Bucket Capacity |
0.07m³ |
|
Max. Digging Height |
3980mm |
|
Max. Digging Depth |
2430mm |
|
Max. Digging Radius |
4136mm |
|
Travel Speed |
2.6/4.5Km/h |
|
Certificate |
CE ISO9000 |
|
Warranty |
1 Year |
|
Hydraulic Cylinder Brand |
Liyuan |
|
Hydraulic Pump Brand |
Kawasaki |
|
Hydraulic Valve Brand |
Eaton |
|
Engine Brand |
Kubota |
|
UNIQUE SELLING POINT |
EPA or euro 5 |
|
Engine Power |
14/2400 kw/rpm |
|
Machinery Test Report |
Provided |
|
Video outgoing-inspection |
Provided |
|
Marketing Type |
New Product 2022 |
|
Warranty of core components |
1 Year |
|
Core Components |
Engine, Gear, Motor, Pump, Gearbox |
|
Overall Dimensions(L*W*H) |
3850*1300/ 1500*2380(mm) |
|
Track Width(mm) |
230(mm) |
|
Min.Turning Radius of work equipment |
1850(mm) |
|
Min.Turning Radius of Tail |
750(mm) |
|
Max. Digging Radius at Ground Level |
4100(mm) |
|
Operation method |
Hydraulic pilot control, hydraulic safety lock of the whole machine |
|
Maximum flow |
1.216L/cc |
|
Hydraulic System Pressure |
20.6(MPa) |
|
Max. Digging Force |
19.5kn |
|
Swing boom angel |
75/ 55° |
